ESPECIFICAÇÕES TÉCNICAS
Características Físicas
| Dimensions | 10.8 in W x 7.8 in L x 0.7 in H (275mm W x 199mm L x 18.3mm H) |
| Weight | 2.6 lbs (1,200g) |
| Display | 10.1 in WUXGA (1920 x 1200) — 1,000 nits; optically bonded to touchpanel |
| Touchpanel | Capacitive multi-touch, Corning® Gorilla® Glass, AI Powered Touch Control for automatic optimization and precise interaction with included passive stylus, MPP 2.0 Active Pen Compatible |
| Connectivity | Docking connector (charge and data); keyboard connector; one USB 3.1 Type A port; two ThunderboltTM 4/USB4 Type C ports |
| Interface Ports and Expansion | Docking connector (charge and data); Keyboard connector; 1 x USB 2.0 (back I/O – host only) |
| Notifications | Audible tone; 1 multi-color LED |
| Audio | Stereo speakers and two microphones; audio headset supported through USB port or Bluetooth; speaker/microphone support |
| Buttons | Power; Scan; Up/Down (programmable); three programmable keys |
| External Scanner Support | HID via USB and Bluetooth®; scanner configuration with Zebra 123Scan, Zebra Scanner SDK |
Características de Desempenho
| CPU | Intel® Core™ Ultra 5 125U Intel® Core™ Ultra 5 135U (vPro®) Intel® Core™ Ultra 7 155U Intel® Core™ Ultra 7 165U (vPro®) |
| Operating System | Windows® 11 Professional 64 bit, Windows® 11 IoT Enterprise LTSC |
| Memory | 8, 16, 32 GB LPDDR5 RAM |
| Storage | 128 GB, 256 GB, 512 GB, 1 TB, 2 TB tool-less user removable M.2 2230 PCIe NVMe SSD 256 GB, 512 GB tool-less user removable M.2 2230 Opal SED SSD |
Características Ambientais
| Operating Temp. | -20F to +145F (-29C to +63C) |
| Storage Temp. | -40F to +158F (-40C to +70C) |
| Humidity | 5% to 95% non-condensing |
| Drop Specifications | Exceeds MIL-STD-810H 6 ft (1.8m) to tile over concrete across operating temperature range -20F to +145F (-29C to +63C) 5 ft (1.5m) to concrete across operating temperature range -20F to +145F (-29C to +63C) |
| Sealing | IP66 per IEC 60529 |
| Shock/Vibration | MIL-STD-810H Method 514.8 and 516.8 |
| Thermal Shock | MIL-STD-810H: 40F to +158F (-40C to +70C) |
| Electromagnetic Compatibility | MIL-STD-461G, MIL-STD-464D (HERO Certification), EN 55032, EN 55024 |
| Electrostatic Discharge | IEC61000-4-2, ± 15 kV air discharge; ± 8 kV contact; ± 8 kV indirect |
| Salt Fog | MIL-STD-810H, 48h of 5% solution at +95F (+35C) |
| Solar Radiation | EN/IEC 60068-2-5 solar radiation spectral energy distribution; 1120 W/m2 at display surface; Environmental temperature: +104F (+40C); irradiation duration: 24 hours |
| Impact | IEC EN 60079-15, Ball drop; 5 Joules on touch screen |
| Hazardous Location Certification | Class 1 Division 2 (select configurations)2 |
| Vehicle Certifications | E-Mark Europe 12V system ECE Regulation No. 10 Rev. 6 (Tablet with keyboard in docking station) |
Alimentação
| Charging | 45W USB Power Delivery 3.0 through either USB-C port, or optional dock |
| Battery | Standard capacity: 36Wh Extended capacity: 72Wh |
| True Hot Swap | Minimum 60 seconds over the full operating temperature range with internal super capacitor |
| Battery Charge Time | Standard battery: 2.5 hrs from 0% to 100% with 45W power supply Extended battery: 5 hrs from 0% to 100% with 45W power supply |
Sensores
| Ambient Light Sensor | Automatically adjusts display brightness |
| Magnetometer | eCompass |
| Motion Sensor | 3-axis gyroscope; 3-axis accelerometer |
| Fingerprint Sensor | Windows® Hello fingerprint reader |
Cameras e Scanner
| Optional Integrated Scanner | SE55 1D/2D Advanced Range Scan Engine with IntelliFocus™ technology |
| Rear Camera | 13 MP autofocus; flash LED generates balanced white light |
| Front Camera | 5 MP RGB with mechanical privacy shade Infrared camera for Windows® Hello support |
Wireless LAN
| Radio | IEEE 802.11-2020 and select amendments (selected feature coverage) IEEE 802.11a, b, d, e, g, h, i, k, n, r, u, v, w, ac, ax, be; Fine Timing Measurement based on 802.11-2016, 802.11az HW readiness |
| Data Rates | Up to 5.8 Gbps; 2×2 MU-MIMO; 320 MHz channels; 4096-QAM; 6 GHz, 5 GHz, and 2.4 GHz bands |
| Operating Channels | 2.4 GHz: Channel 1-13; Bandwidth: 20/40 MHz 5.0 GHz: Channel 36-165; Bandwidth: 20/40/80 MHz 6.0 GHz: Channel 1-221; Bandwidth 20/40/80/160/320 MHz |
| Security and Encryption | WPA3 personal and enterprise including WPA2 transition mode; 802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0 -MSCHAPv2 (EAP-SIM, EAP-AKA, EAP-AKA’), 128-bit AES-CCMP, 256-bit AES-GCMP |
| Fast Roam | 802.11r Fast Transition, 802.11k |
| Certifications | Wi-Fi 7 Technology support, Wi-Fi CERTIFIEDTM 6 with Wi-Fi 6E, Wi-Fi CERTIFIED a/b/g/n/ac, WMM, WMM-Power Save, WPA3, PMF, Wi-Fi Direct, Wi-Fi Agile Multiband, Wi-Fi Location R2 HW readiness |
Wireless WAN (apenas para o ET65W)
| SIM Slots | 1 x eSIM; 1 x Nano SIM |
| Frequency Bands | 5G NR: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/ 71/75/76/77/78/79 LTE-FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/ 30/32/66/71 LTE-TDD: B34/38/39/40/41/42/43/48 LTE LAA: B46 UMTS WDCMA: B1/2/4/5/8/19 |
| LTE/5G Private Networking | Supported |
| GNSS | GPS, GLONASS, BDS (BeiDou), Galileo, QZSS |
Wireless PAN
| Bluetooth | Bluetooth® 5.4 (Class 1), Bluetooth® Low Energy (BLE) |
| NFC | P2P: ISO 18092; Reader/Writer: ISO 14443 –A-B, MIFARE, FeliCa®, ISO 15693, NFC Forum Tag Types 1 to 4; Card emulation: ISO 14443 –A-B-B’, MIFARE, FeliCa RF |
Características de Segurança
|
Discrete TPM v2.0; NIST BIOS compliant; FIPS 140-2 Validated; Common Criteria certified; Windows® Hello front facing camera; Windows® Hello fingerprint reader (optional); contactless NFC Smart Card reader; insertable Common Access Card (CAC) Smart Card reader (optional); Absolute Persistence® technology embedded in BIOS*; Kensington cable lock slots available on the tablet only or the tablet with the keyboard attached. *Requires software and activation |
Periféricos e Acessórios
| Accessories include: vehicle dock; keyboard; CAC/Smart Card reader; RFID reader; 2-slot battery charger; active stylus; carrying accessories — handstrap, kickstand, shoulder strap and handle |
