Principais Especificações
| Processor | Intel® 14th Gen Core i9-14900/ i7-14700/ i5-14500 (TDP 65W) |
| System Memory | Support Dual Channel DDR5 5600Mhz SODIMM up to 96GB |
| Expansion | M.2 2280 M Key x1 |
| OS Support | Windows® 10, Windows® 11, Linux® |
| MXM Graphics | NVIDIA RTX A1000/A2000/A4500 |
| Storage Disk Driver | M.2 2242 M Key NVMe x 1 |
| Wireless Communication | 802.11 ax (optional),Bluetooth 5.3 (optional) |
| Function Key | Power on/off, LCD up/down, Touch enable/disable, Reading Light enable/disable |
| Speaker | 2W x 2 |
| Security | Trusted Platform Module 2.0 , Imprivata RFID Reader (optional) |
| Power Requirement | Medical Adapter 250W 12V |
Ecrã
| USB | USB 3.2 Gen2 x 4,USB 3.2 Type C x 1 (optional) |
| Ethernet | 2.5 Gigabit LAN x 1, Gigabit LAN x 1 |
| Video Out | HDMI 2.0b x 2, Display Port 1.4a x 1 |
| Audio | Mic-in, Line-out |
Entradas e Saídas
| USB | USB 3.0 x 4 |
| Serial Port | Isolated RS-232 x2(optional) |
| Ethernet | Isolated Gigabit LAN x2 |
| Audio | Mic(optional), Line out(optional) |
| Video Out | Display Port 1.4 x1 |
Condições Mecânicas e Ambientais
| Operating Temperature | 0°C ~ 35°C(32°F ~ 95°F) |
| Storage Temperature | -20°C ~ 60°C(-4°F ~ 140°F) |
| Mounting VESA | 100 mm |
| Degree of Protection | IP65 in the front ; IPX1 in the back |
| Dimension | TBC |
| Packing Size | TBC |
| Gross Weight | TBC |
| Net Weight | TBC |
| Certifications | CE: EN 60601-1-2:2015(V4.1) FCC: Part 18 Class B UL: ANSI/AAMI ES60601-1:2012 (V3.2) cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.2) |
