ECRÃ
Panel Size: 98″
Panel Type: TFT LCD Module with DLED Backlight
Display Area (mm): 2171.85(H) x 1232.35(V) (97.52”diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840×2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 350 nits (typ.)
Contrast Ratio: DCR: 3000:1
Response Time: 8ms(TYP.)
Viewing Angles: H = 178, V = 178typ.
Backlight Life: 30,000 Hours (Min)
Surface Treatment: Anti-glare
CPU e MEMÓRIA
Processor: ARM Cortex A73*4
RAM: 4GB DDR4
Storage: 32GB
TOUCH
Type/ Tech: Ultra fine touch technology
Touch Resolution: 32768 ×32768
Touch Point: 20 points touch, 10 points writing
SISTEMA OPERATIVO
Android 9
ENTRADAS
HDMI: HDMI 2.0 x3 (3840×2160 @60Hz)
RGB / VGA: x 1
Audio: x 1
RS232: x 1
OPS: X1 PC Slot
WiFi: x 1 WiFi Slot
Top Camera Plate
SAÍDAS
HDMI: HDMI out 2.0 x1 (3840×2160 @60Hz)
Audio: 3.5mm * 1
SPDIF: x1
PORTAS
LAN RJ45: x2
USB Type A: USB2.0 x 1USB3.0 x 4
USB Type B: x2, for touch
USB Type C: x1
COLUNAS
16Wx2
|
COMPATIBILIDADE
RGB PC/HDMI PC: 1920×1080
HDMI: 4K 60Hz/30Hz/1080p
Slot-in PC: VPC12-WPO series/VPC25-O series/VPC27-O series
SOFTWARE
Basic Annotation Software: myViewBoard for android
Pro Annotation Software: myViewBoard for windows (Embedded in Windows Slot-in PC)
Wireless Presentation: Viewboard Cast
CARACTERÍSTICAS ADICIONAIS
All-in-one USB port: Front “SmartPort USB” to all channels.
Simple LAN sharing between IFP and slot-in device: Yes
Light Sensor: Yes
ALIMENTAÇÃO
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: On mode: 192.5W, Off mode< 0.5W
ERGONOMIA
Wall Mount (VESA® ): 800*600
CONDIÇÕES DE OPERAÇÃO
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% RH non-condensing
DIMENSÕES
Produto (mm): 2245 x 1323 x 91 mm
Embalagem (mm): 2435 x 1483 x 346 mm
PESOS
Net (kg): 103.6 kg
Gross (kg): 133.2 kg
REGULAMENTOS
FCC, cTUVus, EPEAT, ES8, LBL, CE, CB, RCM
CONTEÚDO
1. Power cord
2. Remote control with AAA battery
3. USB cable for touch
4. Touch pen x 2
5. Quick Start Guide
6. RS232 adapter
7. Clamp x 5
8. Camera plate
9. Screw x 8
10. HDMI cable
11. USB Typc-C cable |
