ECRÃ
Screen Size: 98″
Back Light Type: Direct
Native Resolution: 3840×2160 (UHD)
Refresh Rate: 60Hz
Brightness: 440nit(wo Glass, max), 390nit (wo Glass, typ), 400nit(w Glass, typ), 350nit (w Glass, typ)
Contrast Ratio: 1200:1
Dynamic CR: 3000:1
Color gamut: NTSC 72%
Viewing Angle(H x V): 178°(H/V)
Color Depth: 1.07B(10bit)
Response Time: 8ms
Surface Treatment(Haze): 25%
Life time: 50,000hrs (L30)
Operation Hours (Hours/Day): 16/7
Portrait / Landscape: No / Yes
CONETIVIDADE
Input: HDMI (3, HDCP2.2), RGB (1, VGA), Audio In, RS232C IN, RJ45(LAN), USB3.0 Type A (4), USB2.0 Type A(1), USB Type-C(1, USB-PD, DP-Alt,)
Output: DP Out (HDMI Out), Audio Out (1, Optical 1(SPDIF)), Touch USB (2), RJ45(LAN)
ESPECIFICAÇÕES MECÂNICAS
Bezel Color: Black
Weight(Head): 103.6 Kg
Monitor Dimension (W x H x D): 2244 × 1323 × 91mm
Handle: Yes
Bezel WidthT/R/L/B : 30/27/27/45mm
Packed Weight: 133.2 Kg
Carton Dimensions(W x H x D) (Box outer size): 2406 × 1474 × 280mm
VESA™ Standard Mount Interface: 800×600mm
CARACTERÍSTICAS
HW: Internal Memory (64GB), Built-in Wi-Fi (Slot type), Auto Brightness sensor, Power Indicator
SW: Android 13, Background Image (Booting Logo Image), Multi-screen (PIP (1 external source), PBP(1 external source)), Screen Share (LG CreateBoard Share), Power (Smart Energy Saving (Energy Saving))
CONDIÇÕES AMBIENTAIS
Operation Temperature: 0 ~ 40 °C
Operation Temperature: 0 ~ 40 °C
ALIMENTAÇÃO
Power Supply: 100-240V~ 50/60Hz 5.5A
Power Type: Built-In Power
CONSUMO
Typ.: 395W
Max.: 610W
BTU (British Thermal Unit): 1348 BTU/Hr(Typ.), 2081 BTU/Hr(Max)
DPM: ≤0.5W
Power off: ≤ 0.5W |
SOM
Speacker: Yes (15W x 2)
CERTIFICAÇÃO
Safety: CB / NRTL
EMC: FCC Class “A” / CE / KC
ErP / Energy Star: Yes / Yes
COMPATIBILIDADE OPS
OPS Type Compatible: Yes (Slot)
OPS Power Built In: Yes
COMPATIBILIDADE DE SOFTWARE
LG ConnectedCare: Yes
LG ConnectedCare DMS: Yes (DMS)
ALIMENTAÇÃO
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: On mode: 192.5W, Off mode< 0.5W
LÍNGUA
OSD: English, Denmark, Finnish, German, Korean, Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Spanish, Swedish, Hungarian, Thai
ACESSÓRIOS
Basic: Power Cord 3 M*1, USB Cable(Type A-Type B) 5 M*1, USB Type-C Cable(C to C) 1.8 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional: Wall Mount(WM-L000S), Floor Stand(ST-000F)
CARACTERÍSTICAS ESPECIAIS
Touch – Available object size for touch: Ø2 mm
Touch – Accuracy: ±1.5mm
Touch – Protection Glass Thickness: 4T (Anti-Glare)
Touch – Operating System Support: Windows 7/8/10/Linux/Mac/Android
(Linux/Mac Support one point touch)
Touch – Reponse Time: ≤5ms
Touch – Interface: USB2.0
Touch – Protection Glass Transmission: 88%
Touch – Multi touch point: Max 40 points (Windows), Max 32 points (Android)
SISTEMA ANDROID
SoC: Quad core A55
Internal Memory – Storage: 64GB
Wi-Fi: 802.11a/b/g/n/ac/ax (WiFi 6)
Bluetooth: Bluetooth 5.0
GPU: Mali G52MP2
Internal Memory – RAM: 8GB
LAN: Gigabit LAN |
