Principais Especificações
| AI Engine | NVIDIA Jetson AGX Orin | |
| CPU | 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 (ACCEL-JS1000-N1) 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3(ACCEL-JS1000-N2) |
|
| System Memory | 32GB or 64GB 256-bit LPDDR5 204.8 GB/s | |
| Graphics | 1792-core NVIDIA Ampere GPU with 56 Tensor Cores (ACCEL-JS1000-N1) 2048-core NVIDIA Ampere GPU with 64 Tensor Cores (ACCEL-JS1000-N2) |
|
| Storage | 64GB eMMC 5.1 , M.2 NVMe Storage (Optional) | |
| OS support | Linux with Jetpack OS | |
| Security | TPM 2.0 | |
| Speaker | 2W x Speaer x 2 | |
Entradas e Saídas
| USB | USB Type C x 2 for USB 3.2 , one only support APX mode USB Type A x 2 for USB 2.0 |
|
| Ethernet | Gigabit LAN x 1 | |
| Video Out | HDMI 2.0 x 1 | |
| Video input (Optional) | 3G SDI or 12G SDI,or HDMI 3G SDI(Max resolution up to 1920×1080p@60fps), 12G SDI(Max resolution up to 4096×2160@60fps) HDMI (Max resolution up to 1920×1080p@60fps) |
|
| Audio | Mic-in x 1 , Line out x 1 | |
| Serial Port | RS232 x 1 | |
| Function Port | Reset Button x 1 ,Recovery Button x 1, Grounding pin x 1 |
|
| DC-in | 12V DC Jack | |
| Front I/O | Power Button with Power LED indicator x 1 | |
| Wireless Communication | 802.11a/b/g/n/ac/ax.w/BT5.2 (Optional) | |
| Expansion I/O | PCIe [x8] x 1(Optional) | |
Condições Mecânicas e Ambientais
| Power | Medical adapter 12V 120W | |
| Operating temperature | 0°C ~ 35°C(32°F ~ 95°F) | |
| Storage temperature | -20°C ~ 60°C(-4°F ~ 140°F) | |
| Dimension | 220(W) x 150(D) x 87.8(H) mm | |
| Package Size | 295 x 230 x 208 mm | |
| Gross Weight | 3.4 KG | |
| Net Weight | 1.8KG | |
| Certifications | CE: EN 60601-1-2: 2015 + A1: 2021 (V4.1), EN 60601-1: 2007 + A1:2013 +A2:2021 (V3.2) EN 55032:2015/A1:2020 EN 55035:2017/A11:2020 (ITE) IEC 62368-1:2020+A11:2020 (ITE) FCC: Part 15B/ Part 18 UL: ANSI AAMI ES60601-1:2005/A1:2012/ A2:2021(V3.2) cUL: CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1: 2005+A1:2012+A2:2020,MOD) (V3.2) |
|
