Principais Especificações
| UP-43P (Power Bank) | UP-43L (Charger only) | |
| Output Voltage | DC out x3 Selectable voltage for each port. 12/15/19/24V (only one voltage at the same time for one port) |
N/A |
| Output Capacity | Normal mode : share 90W with 2 port Power mode : 90W for ch1; 65W for ch2 Medical 45W AC output (optional) |
N/A |
| Charge Time | 6hrs for XL battery; 8hrs for XXL battery (no charge when power output) |
Normal Charge: 8hrs for XL battery; 10hrs for XXL battery Fast Charge: 3.5hrs for XL |
| Function Key | Power Mode Button : Normal(max capacity) Power mode(max output) Charge Button : Power output charger |
Fast Charge Button : normal charge fast charge |
| Extend Function | Adaptor holder (optional) Cart mount bracket (optional) UP board (optional) 45W Medical AC inverter (optional) |
Adaptor holder (optional) Cart mount bracket (optional) |
| Safety |
Supports protection from over-voltage (input), over-current (input and output), short circuit, over-charge. |
|
| Certification | CE, FCC, IEC60601-1 | |
Condições Mecânicas e Ambientais
| Architecture | ABS + PC | |
| Color | White | |
| Dimension | 255(L) x 160(W) x 213(H) mm | |
| Net Weight | 1kg (1.47 lbs) (w/o battery) | |
| Operating Temperature | 0°C ~ 35°C(32°F ~ 95°F) | |
| Storage Temperature | -20°C ~ 60°C(-4°F ~ 140°F) | |
| Storage Humidity | 10%~95%@35°C, non-condensing | |
Alimentação
| Input Voltage | 100-240V AC @50-60 Hz | |
| Output Power | 24V / 250W max | |
